Intel Processor G4400T OEM | FCLGA 1151

Essentials

Product Collection: Intel® Pentium® Processor G Series
Code Name: Products formerly Skylake
Vertical Segment Desktop
Processor Number G3450
Lithography 14 nm

Performance Specifications

# of Cores 2
# of Threads 2
Processor Base Frequency 2.90 GHz
Cache 3 MB Intel® Smart Cache
Bus Speed 8 GT/s
TDP 35 W

Supplemental Information

Embedded Options Available No

Memory Specifications

Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4-1866/2133, DDR3L-1333/1600 @ 1.35V
Max # of Memory Channels 2
Max Memory Bandwidth 34.1 GB/s
ECC Memory Supported  Yes

Processor Graphics

Processor Graphics  Intel® HD Graphics 510
Graphics Base Frequency 350 MHz
Graphics Max Dynamic Frequency 950 MHz
Graphics Video Max Memory 64 GB
Graphics Output eDP/DP/HDMI/DVI
Max Resolution (HDMI 1.4) 4096×2304@24Hz
Max Resolution (DP) 4096×2304@24Hz
Max Resolution (eDP – Integrated Flat Panel) 4096×2304@24Hz
Max Resolution (VGA) N/A
DirectX* Support 12
OpenGL* Support 4.4
Intel® Quick Sync Video Yes
Intel® Clear Video HD Technology Yes
# of Displays Supported  3
Device ID0x1902

Expansion Options

Scalability 1S Only
PCI Express Revision Up to 3.0
PCI Express Configurations  Up to 1×16, 2×8, 1×8+2×4
Max # of PCI Express Lanes 16

Package Specifications

Sockets Supported FCLGA1151
Max CPU Configuration 1
Thermal Solution Specification PCG 2015A (35W)

Advanced Technologies

Intel® Turbo Boost Technology  No
Intel vPro® Platform Eligibility  No
Intel® Hyper-Threading Technology  No
Intel® Virtualization Technology (VT-x)  Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes
Intel® VT-x with Extended Page Tables (EPT)  Yes
Intel® Transactional Synchronization Extensions No
Intel® 64  Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Intel® Identity Protection Technology  Yes
Intel® Stable Image Platform Program (SIPP) No

Security & Reliability

Intel® AES New Instructions Yes
Secure Key Yes
Intel® Software Guard Extensions (Intel® SGX) Yes with Intel® ME
Intel® Memory Protection Extensions (Intel® MPX) No
Intel® OS Guard No
Intel® Trusted Execution Technology  No
Execute Disable Bit  Yes
Intel® Boot Guard Yes
