Characteristics

• LCD screen indicates the status of the UPS in real time
• LCD with blue illumination for easy reading
• Power protection for home or office equipment
• Voltage regulator (AVR), regulates voltage rises and falls
• 6 battery backup output jacks, AVR (4), surge suppression (2)
• Network, fax and modem protection (RJ-45)
• USB port for communication with PC
• Long backup time
• Management software included
• 660 Joules of protection
• Coaxial line protection
• Typical applications
• Home theater equipment
• Video game consoles
• High-end PCs
• High-end PCs for small and medium offices
• Work stations
• Entry level servers
• Electronic equipment

Specifications

CAPACITY:

• 2200VA / 1200W

ENTRY:

• Nominal voltage 220/230/240 VAC
• Voltage range 166 280 VAC
• Frequency range 50 / 60Hz

DEPARTURE:

• Voltage regulation / 10% (battery mode)
• Frequency regulation / 1 Hz (battery mode)
• Frequency range 45.0Hz ~ 55.0Hz
• Output Waveform Modified Sine Wave

TRANSFER TIME:

• Typical 4-8ms

DRUMS:

• Battery type 2 units of 12V / 9Ah
• Autonomy time * 45 minutes
• Recharge time 6 hours at 90% of capacity after full discharge

AUDIBLE ALARM

• Standby time Activates every 10 seconds
• Low battery voltage Activates every 1 second
• Overload Activates every 0.5 second
• Battery change Activates every 2 seconds
• Continued Sound Failure

PROTECTION

• Total protection Sudden discharge, overload and voltage surges

PHYSICAL CHARACTERISTICS

• Dimensions DxWxH (mm) 400 x 145 x 205
• Net weight 10.8 kg

ENVIRONMENTAL ASPECTS

• Operating environment 040 ° C, relative humidity 0 to 90% (non-condensing)
• Noise level below 40dB

INTERFACE

• USB port, Windows® 9 / XP / Vista / 7, MAC OS, Linux
• INDICATOR LCD screen. The LED remains illuminated during normal operation of the unit, while charging, and when it enters fault mode.
